Line Pressure Regulator
Date：2025-11-22 09:37:48
Clicks：
Editor：未知
Line Pressure Regulator
Standard:
EN334, EN88, ISO23555, ANSI B109.5, UL144, ISO15500-9, etc.
Corrosion Standard:
NACE MR 0175, ISO-1516.
Body Material:
ASTM A216 WCB, Spheroidal Graphitic Cast Iron, Alloy, etc.
Inlet Nozzle Range:
1/4" To 2".
Inlet Nozzle Type:
NPT-F, NPT-M
Angle between Inlet & Outlet:
90Deg or 180Deg
Outlet Nozzle Range:
1/4" To 2".
Outlet Nozzle Type:
NPT-F, NPT-M
Design Pressure:
< Class 150.
Max. Inlet Pressure:
250 psig.
Max. Outlet Pressure:
100 psig.
Working Temperature:
-55F to 350F.
Medium:
Natural gas, Air, etc.
Max. Capacity:
100,000 SCFH.
Noise:
<60dB.
Corrosion Allowance:
As per customer' requirement.
Painting:
Anti-rust paint, or as per Customer's requirement.
Inspection & Test:
MT, UT, RT, PT, Dimension inspection, Pneumatic test, etc.
Packing:
Strong & standard export packing or Customer's requirement.
